Mulchers / FAE

FAE

Teeth and parts for FAE forestry mulchers.

Contact Us for Inquiries
Back to Mulchers

KFS542-1

$ - contact for price and availability

Carbide tipped replacement tooth type "C" fitting FAE, Caterpillar and Rayco forestry mulchers Length: 99 mm Width: 60 mm Height: 72 mm Wear protection: Carbide tipped Fitting bolt size: 20 mm Thread type: Metric Thread: yes Thread pitch: Fine thread Number of bolts: 1 Number of cutting edges: 1 Number of carbide tips: 2

KFS542-2-P

$ - contact for price and availability

Carbide tipped replacement tooth fitting FAE, Caterpillar and Rayco forestry mulchers Length: 99 mm Width: 60 mm Height: 72 mm Wear protection: Grit Fitting bolt size: 20 mm Thread type: Metric Thread: yes Thread pitch: Fine thread Number of bolts: 1 Number of cutting edges: 1 Number of carbide tips: 2

KFS1328

$ - contact for price and availability

Replacement tooth type "C" fitting FAE, Caterpillar and Rayco forestry mulchers Length: 82 mm Width: 60 mm Height: 48 mm Wear protection: Hardened Thread type: Inch Fitting bolt size: 5/8" Thread: yes Thread pitch: Fine thread Number of bolts: 2 Distance from hole to hole: 35 mm Number of cutting edges: 1

KFS1293-PLA2

$ - contact for price and availability

Replacement tooth type "C" fitting FAE, Caterpillar and Rayco forestry mulchers Length: 99 mm Width: 68 mm Height: 73 mm Wear protection: Laser Thread type: Metric Fitting bolt size: 20 mm Thread: yes Thread pitch: Fine thread Number of bolts: 1 Number of cutting edges: 1

KFS1268

$ - contact for price and availability

Carbide tipped replacement tooth type "STCL 3" fitting FAE rock crushers and FAE soil stabilizers as well as FAE, Caterpillar and Rayco forestry mulchers Length: 9 mm Width: 58 mm Height: 74 mm Wear protection: Carbide tipped Fitting bolt size: 20 mm Thread type: Inch Thread: no Thread pitch: n/a Number of bolts: 1 Number of cutting edges: 1 Number of carbide tips: 2

KFS1226

$ - contact for price and availability

Carbide tipped replacement tooth type "C3" fitting FAE, Caterpillar and Rayco forestry mulchers Length: 79 mm Width: 58 mm Height: 74 mm Wear protection: Carbide tipped Fitting bolt size: 20 mm Thread type: Inch Thread: no Thread pitch: n/a Number of bolts: 1 Number of cutting edges: 1 Number of carbide tips: 2

KSI109

$ - contact for price and availability

Bolt M20x1,5x70mm Bolt diameter, metric:20 mm Length, metric:60 mm Thread type:Metric Bolt head style:Allen head mm Grade:12.9 DIN Norm:DIN 912 Thread pitch:Fine thread

KSI110

$ - contact for price and availability

Washer M20 Schnorr-washer Type:Schnorr Fitting bolt size:metric 20 mm

KSI114

$ - contact for price and availability

Washer M20 Nordlock washer Type:Nordlock Fitting bolt size:metric 20 mm

KFS1268-P

$ - contact for price and availability

Carbide tipped replacement tooth type „STCL 3“ with two rock-crushing tungsten carbide tips, additional KingGrit hardfacing on the steel body and one mounting hole for a hammerhead bolt fitting FAE rock crushers and FAE soil stabilizers as well as FAE,Caterpillar and Rayco forestry mulchers Severe duty version For rocky ground conditions Ground level mulching and soil stabilizing Length:79 mm Width:58 mm Height:74 mm Wear protection:Carbide tipped Fitting bolt size:metric 20 mm Thread type:Inch Number of bolts:1 Number of cutting edges:1 Number of carbide tips:2

KFS1367

$ - contact for price and availability

Carbide tipped sidescraper tooth type „STCL 3“ with two rock-crushing tungsten carbide tips, additional carbide wear protection on the steel body (right side) and one mounting hole for a hammerhead bolt Right severe duty version Used on the outer position of the rotor Length:84 mm Width:65 mm Height:73 mm Wear protection:Carbide tipped Fitting bolt size:metric 20 mm Thread type:Inch Number of bolts:1 Number of cutting edges:1 Number of carbide tips:6 Saddleback:Yes

KFS1368

$ - contact for price and availability

Carbide tipped sidescraper tooth type „STCL 3“ with two rock-crushing tungsten carbide tips, additional carbide wear protection on the steel body (left side) and one mounting hole for a hammerhead bolt Left severe duty version. Used on the outer position of the rotor Length:84 mm Width:65 mm Height:73 mm Wear protection:Carbide tipped Fitting bolt size:metric 20 mm Thread type:Inch Number of bolts:1 Number of cutting edges:1 Number of carbide tips:6 Saddleback:Yes

KFS1369

$ - contact for price and availability

Carbide tipped replacement tooth type „K3“ with extra big rock crushing carbide tip and one M20 fine thread. Severe duty version. Ground level mulching, very abrasive applications. Length:78 mm Width:58 mm Height:92 mm Wear protection:Carbide tipped Fitting bolt size:metric 20 mm Thread type:Metric Thread:yes Thread pitch:Fine thread Number of bolts:1 Number of cutting edges:1 Number of carbide tips:1 Saddleback:Yes

KFS1323

$ - contact for price and availability

Replacement tooth type „C3“ with cutting edge sharpened and one mounting hole for a hammerhead bolt. Aggressive version Best choice if aggressive cutting action is needed. Length:79 mm Width:66 mm Height:77 mm Wear protection:Hardened Thread type:Inch Fitting bolt size:metric 20 mm Number of bolts:1 Number of cutting edges:1 Saddleback:Yes

KFS1264-PLA2

$ - contact for price and availability

Replacement tooth type „C3“ with cutting edge sharpened, additional PLA hardfacing on the cutting edge and one mounting hole for a hammerhead bolt. Aggressive version. Aggressive cutting action, especially designed for abrasive applications. Length:79 mm Width:66 mm Height:77 mm Wear protection:Laser Thread type:Inch Fitting bolt size: metric20 mm Number of bolts:1 Number of cutting edges:1

KFS1370

$ - contact for price and availability

Replacement tooth type C3“ with cutting edge sharpened and one mounting hole for a hammerhead bolt. Aggressive version. Best choice if aggressive cutting action is needed. Length:85 mm Width:66 mm Height:50 mm Wear protection:Without Thread type:Inch Fitting bolt size:metric 20 mm Number of bolts:1 Number of cutting edges:1 Saddleback:Yes

KFS1371

$ - contact for price and availability

Tool holder of the two-piece tool system type C3“ made of wear resistant steel, with special tool mounting and one mounting hole for a hammerhead bolt. Standard version. For all mulching applications recommended. Width:61 mm Mounting type:Bolted Wear protection:Without Number of bolt holes:1 Thread type:Inch Fitting bolt size:metric 20 mm

KSI146

$ - contact for price and availability

Conical washer M20, 36/21x5 Standard washer type DIN Norm:DIN6796 Fitting bolt size:metric20 mm

KSI137

$ - contact for price and availability

Nut M20x1,5 - 10.9 DIN980 Hex nut style DIN Norm:DIN 980 Fitting bolt size:metric 20 mm Thread type:Metric Grade:10.9 Thread pitch:Fine thread

KFS456-1

$ - contact for price and availability

Carbide tipped replacement tooth type „C“ with embedded tungsten carbide tips and two M16 fine threads. Standard version For most applications recommended ground level mulching Compatible hardware: SI302, SI303, KSI111 Length:99 mm Width:53 mm Height:64 mm Wear protection:Carbide tipped Fitting bolt size:metric 16 mm Thread type:Metric Thread:yes Thread pitch:Fine thread Number of bolts:2 Distance from hole to hole:38 mm Number of cutting edges:1 Number of carbide tips:2

KFS541

$ - contact for price and availability

Carbide tipped replacement tooth type „C“with embedded tungsten carbide tips, additional carbide wear protection on the steel body and two M16 fine threads. Severe duty version Used on the outer position of the rotor Compatible hardware: SI302, SI303, KSI111 Length:99 mm Width:53 mm Height:64 mm Wear protection:Carbide tipped Fitting bolt size:metric 16 mm Thread type:Metric Thread:yes Thread pitch:Fine thread Number of bolts:2 Distance from hole to hole:38 mm Number of cutting edges:1 Number of carbide tips:8

KFS1207

$ - contact for price and availability

Replacement planer tooth type „E“ made out of wear resistant steel with sharp cutting edges and with one M14 fine thread. Aggressive and reversible version Best choice if aggressive cutting action is needed Length:59 mm Width:57 mm Height:44 mm Wear protection:Hardened Thread type:Metric Fitting bolt size:metric 14 mm Thread:yes Thread pitch:Fine thread Number of bolts:1 Number of cutting edges:2

KFS1207-PLA2

$ - contact for price and availability

Replacement planer tooth type E“ made out of wear resistant steel with sharp cutting edges, additional PLA hardfacing on the cutting edges and with one M14 fine thread. Aggressive and reversible version. Best choice if aggressive cutting action is needed, especially designed for abrasive applications Length:59 mm Width:57 mm Height:44 mm Wear protection:Laser Thread type:Metric Fitting bolt size:metric 14 mm Thread:yes Thread pitch:Fine thread Number of bolts:1 Number of cutting edges:2

KFS1208-1

$ - contact for price and availability

Carbide tipped replacement tooth type EHD“ with three embedded tungsten carbide tips and one M14 fine thread. Severe duty version Clean material without contamination; abrasive applications Length:54 mm Width:53 mm Height:36 mm Wear protection:Carbide tipped Fitting bolt size:metric 14 mm Thread type:Metric Thread:yes Thread pitch:Fine thread Number of bolts:1 Number of cutting edges:1 Number of carbide tips:3 Saddleback:No

KSI194

$ - contact for price and availability

Bolt M14x1,5x30 12.9 DIN912 Bolt diameter:metric 14 mm Length, metric:30 mm Thread type:Metric Bolt head style:Allen head mm Grade:12.9 DIN Norm:DIN 912 Thread pitch:Fine thread

KHS001

$ - contact for price and availability

Tool holder type „C“ with one M20 mounting hole, fitting rotors with radius r= 98 mm Standard version For all mulching applications recommended Width:44 mm Mounting type:Welded Rotor diameter:196 mm Wear protection:Without Number of bolt holes:1 Thread type;Inch Fitting bolt size, metric:20 mm

KSI241

$ - contact for price and availability

Hammer head bolt Bolt diameter, metric:20 mm Length, metric:120 mm Thread type:Metric Bolt head style:Hammer head mm Grade:12.9 Thread pitch:Fine thread

KFS1216

$ - contact for price and availability

Carbide tipped side scraper tooth type MH“ with embedded tungsten carbide wear protection and two M16 fine threads. Left version used as external tooth of the rotor Length:144 mm Width:70 mm Height:116 mm Wear protection:Carbide tipped Fitting bolt size, metric:16 mm Thread type:Metric Thread:yes Thread pitch:Fine thread Number of bolts:2 Distance from hole to hole:38 mm Number of cutting edges:1 Number of carbide tips:7

KFS1217

$ - contact for price and availability

Carbide tipped side scraper tooth type „MH“ fitting FAE forestry mulchers and soil stabilizers Tooth with embedded tungsten carbide wear protection and two M16 fine threads Right version Application recommendation: used as external tooth of the rotor Length:144 mm Width:70 mm Height:116 mm Wear protection:Carbide tipped Fitting bolt size, metric:16 mm Thread type:Metric Thread:yes Thread pitch:Fine thread Number of bolts:2 Distance from hole to hole:38 mm Number of cutting edges:1 Number of carbide tips:7

KSI140

$ - contact for price and availability

Hammerhead Bolt Bolt diameter:20 mm Length:130 mm Thread type:Metric Bolt head style:Hammer head mm Grade:12.9 Thread pitch:Fine
